Components
The Coleo system consists of five major components that work together.
Brain (Coordinator)
The Brain is the central nervous system of Coleo.
┌─────────────────────────────────────────────────────────────┐
│ BRAIN │
├─────────────────────────────────────────────────────────────┤
│ Responsibilities: │
│ ├── Arm Lifecycle - Spawn, monitor, kill arms │
│ ├── Conflict Resolution - Mediate ownership disputes │
│ ├── Governance - Process proposals, enforce rules │
│ ├── Human Interface - Route approvals, notifications │
│ ├── State Management - Persist system state │
│ └── Misbehavior Detection - Identify and stop bad actors │
├─────────────────────────────────────────────────────────────┤
│ Powers: │
│ ├── PAUSE arm - Temporarily halt an arm │
│ ├── KILL arm - Terminate destructive arm │
│ ├── VETO proposal - Override arm consensus │
│ └── ESCALATE to human - Require human decision │
└─────────────────────────────────────────────────────────────┘Misbehavior Detection
The Brain monitors arms for problematic behavior:
| Behavior | Detection | Response |
|---|---|---|
| Touching files outside task scope/claims | Pattern matching on file paths vs. claims | WARN, then PAUSE |
| Ignoring consensus without override | Proposal tracking | WARN, reputation penalty |
| Destructive changes | Pattern matching (rm -rf, DROP, etc.) | KILL immediately |
| Resource exhaustion | Token/API call counters | PAUSE, notify human |
| Stuck in loop | Action repetition detection | PAUSE with exponential backoff |
Loop Detection & Backoff Throttling (Design)
When an arm gets stuck in a loop (repeating the same actions, hitting the same errors, or consuming tokens without progress), the brain intervenes with an escalating backoff strategy:
typescript
interface LoopDetection {
armId: string;
detectedAt: Date;
loopType: "action_repeat" | "error_loop" | "token_burn" | "thrashing";
consecutiveLoops: number; // How many times we've caught this arm looping
backoffMinutes: number; // Current pause duration
}
const BACKOFF_SCHEDULE = [
1, // First loop: 1 minute pause
5, // Second: 5 minutes
15, // Third: 15 minutes
30, // Fourth: 30 minutes
60, // Fifth+: 1 hour
];Loop Response Protocol:
- Detect: Brain notices arm repeating actions or burning tokens without progress
- Pause: Arm is immediately paused (cannot consume more tokens)
- Instruct: Brain sends message: "You appear stuck. Compact your session and reassess."
- Wait: Arm remains paused for backoff duration
- Resume: After backoff, arm is resumed with instruction to compact context and retry
- Check Relevance: If original task is no longer relevant, arm is reassigned
typescript
interface LoopRecoveryMessage {
type: "loop_recovery";
armId: string;
instruction: string;
actions: ("compact_session" | "reassess_task" | "request_help")[];
originalTaskStillRelevant: boolean;
pauseDuration: number;
}Token Budget Protection (Design):
typescript
interface TokenThrottle {
windowMinutes: number; // Rolling window (default: 10)
maxTokensPerWindow: number; // Hard cap (default: 50000)
warningThreshold: number; // Warn at 70%
}Brain State
typescript
interface BrainState {
status: "running" | "stopped" | "paused";
startedAt: Date;
lastPollAt: Date;
pollIntervalMs: number;
activeArms: string[];
pendingProposals: number;
pendingApprovals: number;
}Brain Logic
The brain runs a polling cycle every 30 seconds that orchestrates arm lifecycle and task assignment. It includes event-window based arm health monitoring and automatic intervention capabilities.
Poll Cycle
mermaid
flowchart TD
classDef process fill:#e1f5fe,stroke:#01579b,stroke-width:2px
classDef decision fill:#fff3e0,stroke:#e65100,stroke-width:2px,shape:rhombus
subgraph POLL["Poll Cycle - Runs every 30s"]
A[Start Poll] --> B[scanForRunningArms]
B --> C{API Server Available?}
C -->|Yes| D[Get Idle Arms]
C -->|No| E[Skip API Arms]
D --> F[promptIdleArms]
F --> G[checkIdleArmStuckLoops]
G --> H[End Poll]
end
class A,B,D,F,G,H process
class C decisionEvent-Window Based Health Monitoring
The brain continuously monitors arm health using an event-window based system that analyzes recent activity patterns to detect issues before they become critical.
Event Window Analysis
The health monitoring system fetches event windows for each arm from JetStream, grouping events by type and analyzing patterns to classify arm states:
typescript
interface ArmActivityState {
productive: "actively doing useful work";
idle: "waiting for work";
waiting_permission: "blocked on a permission request";
looping: "stuck in a repetitive pattern";
silent: "no events for an extended period";
error: "encountered an error state";
starting: "in startup grace period";
}Health Monitoring Components
- BrainEventWindow: Centralized JetStream event window fetcher that retrieves event slices per arm
- ArmActivityAnalyzer: Classifies arm states based on event windows using pattern recognition
- ArmHealthMonitor: Coordinates health checks and automatic interventions
Automatic Intervention Capabilities
When issues are detected, the health monitoring system can automatically intervene:
- Prompting: Send messages to arms that appear stuck or idle
- Interrupting: Send /compact commands to arms stuck in loops
- Killing: Terminate arms that are consistently problematic
- Escalating: Notify humans for permission requests that timeout
- Recovering: Restart arms that crash or become unresponsive
Configuration Options
The health monitoring system is highly configurable:
typescript
interface HealthMonitorConfig {
checkIntervalMs: number; // How often to run health checks
eventWindowMs: number; // Size of event window to analyze
autoInterventionEnabled: boolean; // Whether automatic interventions are enabled
silentThresholdMs: number; // Time before arm considered silent
loopRepetitionThreshold: number; // Repetitions before considering looping
permissionEscalationMs: number; // Time before escalating permission requests
}File Reading During Poll
The brain reads markdown files during its poll cycle to sync tasks from human-editable sources:
Poll Cycle File Reading:
├── Step 8: syncPlanTasks()
│ └── Reads .project/plan.md
│ └── Extracts tasks from `- [ ]` checkbox items
│ └── Creates/updates tasks in SQLite
│
├── Step 8a: processInbox()
│ └── Reads .project/inbox.md
│ └── Parses ## headers and - [ ] items as new tasks
│ └── Deduplicates against existing tasks (by title similarity)
│ └── Clears inbox after processing
│
├── Step 8b: checkDocUpdateTrigger()
│ └── Checks if documentation needs updating
│
└── Step 8c: reEvaluatePlanProgress()
└── Creates verification tasks for issuesFiles the brain reads:
.project/plan.md- Main plan with phases and deliverables.project/inbox.md- Quick task input (cleared after processing)**/*.plan.md- Any file ending in .plan.md**/plans/*.md- Files in plans/ directories
Arm State Machine
Arms follow a formal state machine with 7 states:
mermaid
flowchart LR
classDef state fill:#f3e5f5,stroke:#4a148c,stroke-width:2px
subgraph LIFECYCLE["Arm State Machine"]
direction LR
disconnected["disconnected<br/>(not tracked)"] -->|scan finds process| idle["idle<br/>(ready for work)"]
idle -->|brain assigns task| task_assigned["task_assigned<br/>(task assigned, awaiting ack)"]
task_assigned -->|arm acknowledges| working["working<br/>(has task, processing)"]
working -->|complete_task| idle
idle -->|no activity after prompt| stuck["stuck detection"]
stuck -->|productive activity detected| working
stuck -->|confirmed stuck| intervention["intervention"]
intervention -->|recover| idle
working -->|process dies| stopped["stopped"]
idle -->|process dies| stopped
task_assigned -->|process dies| stopped
stopped -->|restart| disconnected
end
class disconnected,idle,task_assigned,working,stuck,intervention,stopped stateState Transition Truth Table
| From State | Event | To State | Notes |
|---|---|---|---|
| spawning | PROCESS_STARTED | starting | Process is running |
| starting | HARNESS_CONNECTED | idle | Harness ready |
| idle | TASK_ASSIGNED | task_assigned | Brain assigns task |
| task_assigned | TASK_ACKNOWLEDGED | working | Arm accepts task |
| task_assigned | TIMEOUT (3min) | idle | Arm didn't ack, release task |
| working | TASK_COMPLETED | idle | Task done |
| working | TASK_FAILED | idle | Task failed |
| idle/working | CONNECTION_LOST | disconnected | Network issue |
| disconnected | CONNECTION_RESTORED | previous | Reconnected |
| any | STOP | stopped | Intentional stop |
Task Reordering and Management
Tasks now include a sort_order field that allows manual reordering:
http
POST /api/tasks/reorder
{
"taskId": "task-123",
"toSortOrder": 0 // 0=top, -1=bottom
}Tasks can also be removed directly from plan.md files:
http
POST /api/tasks/:id/remove-from-planThis links plan.md lines to tasks via plan_line_uid and removes both the line and the database entry.
Task Assignment Flow
mermaid
sequenceDiagram
participant Arm
participant Brain
participant DB[SQLite Database]
participant State[State Machine]
Note over Arm,State: Arm is IDLE and waiting
Arm->>Brain: heartbeat (status: idle)
Brain->>Arm: "You have tasks, call get_full_briefing"
Note over Arm: Arm calls get_full_briefing
Arm->>Brain: get_full_briefing()
Brain->>Arm: Task context bundle
Note over Arm: Arm decides to claim task
Arm->>Brain: claim_task(task-id)
Brain->>State: TASK_ASSIGNED event
State->>State: idle → task_assigned
Brain->>DB: UPDATE tasks SET status='claimed', assigned_to=arm
Brain->>DB: UPDATE arms SET status='busy'
Brain->>Arm: task_assignment message (via queue)
Arm->>Brain: acknowledge_task(task-id)
Brain->>State: TASK_ACKNOWLEDGED event
State->>State: task_assigned → working
Brain->>DB: UPDATE tasks SET status='in_progress'
Note over Arm,State: Arm is now WORKING on the taskKey insight: The brain assigns tasks to arms in idle state, transitioning them to task_assigned. The arm must then explicitly acknowledge to transition to working. This two-step process ensures both brain and arm agree on task ownership.
Grace Period for Autonomous Arms
When the brain starts up and finds arms that were working autonomously (before the brain was running), it protects them from being interrupted:
mermaid
sequenceDiagram
participant Brain
participant DB[SQLite Database]
participant Arm
Note over Brain,DB: Brain starts up - finds arm working autonomously
Brain->>DB: scanForRunningArms()
DB->>Brain: arm "rand" exists, status=busy
Brain->>Arm: Check if process alive (kill(pid, 0))
Arm-->>Brain: Process alive!
Brain->>DB: UPDATE arms SET status='idle'
Brain->>DB: armDetectionTimes.set("rand", now)
Note over Brain: Grace period - no prompting for configured time
Brain->>DB: checkIdleArmStuckLoops()
Brain->>DB: Query productive activity in last 60 min
DB-->>Brain: Found: complete_task at 14:30
Brain->>Brain: lastProductiveAt = 14:30<br/>skip stuck detection<br/>arm was working autonomously!
Note over Brain,Arm: Arm continues working without interruptionGrace period behavior:
- Arms detected during
scanForRunningArms()are not prompted for a configurable grace period - Default: 5 minutes
- Configurable via
brain.arm_grace_period_minutesin config.toml - The brain also checks for recent productive activity (heartbeat, claim_task, complete_task) before marking an arm as stuck
Stuck Loop Detection
The brain detects when arms repeatedly respond with "idle" without productive work:
- Idle arm prompting: Brain prompts idle arms to check for work
- Activity tracking: Recent activity is analyzed for prompt-response patterns
- Productive actions: heartbeat, claim_task, acknowledge_task, complete_task, file_changed, tool_call
- Escalation: If arm doesn't respond productively:
- Level 0: Interrupt + different prompt
- Level 1: Force context compaction
- Level 2: Kill and respawn arm
- Level 3: Notify human via email
Arms (General-Purpose Agents)
Each arm is a semi-autonomous general-purpose AI agent. Its behavior is determined by the task classification it is executing (architect, development, QA, documentation, etc.), not by a permanently assigned domain.
Arm Profile
typescript
interface ArmProfile {
id: string;
name: string;
agent: "opencode-api" | "custom";
// Task execution
supportedClassifications: string[]; // e.g., ["architect", "development", "qa"]
// Context Management
contextBudget: ContextBudget;
currentContext: ContextSnapshot;
// Ownership
claims: FileClaim[]; // Files/dirs this arm is tending
// Governance
reputation: number; // 0-100, affects persuasion weight
activeProposals: Proposal[];
// State
status: "idle" | "working" | "blocked" | "proposing" | "paused" | "dead";
currentTask?: Task;
}Arms can be used for different task classifications over time. The same arm might run an architect task for one assignment, then a development or QA task for the next.
MCP Server Catalog
Arms access the garden through MCP servers. Each provides specialized capabilities:
| MCP Server | Purpose | Key Tools |
|---|---|---|
git-mcp | Version control | commit, push, branch, diff, log |
env-mcp | Environment variables | get, set, list (filtered for secrets) |
docs-mcp | Library documentation | search, fetch, summarize |
devtools-mcp | Browser automation | screenshot, console, network, lighthouse |
deploy-mcp | Deployment operations | request, status, rollback, logs |
db-mcp | Database operations | query, migrate, seed, backup |
pkg-mcp | Package management | install, update, audit, outdated |
observability-mcp | Logs & metrics | logs.search, metrics.query, traces.find |
alerts-mcp | Alert management | list, ack, silence, escalate |
Observability MCP Server
For production operations, arms need visibility into running systems:
typescript
interface ObservabilityMCP {
// Log operations
"logs.search": (params: {
service: string;
environment: string;
query: string;
timeRange: { start: Date; end: Date };
limit?: number;
}) => LogEntry[];
"logs.tail": (params: {
service: string;
environment: string;
follow: boolean;
}) => AsyncIterable<LogEntry>;
// Metrics
"metrics.query": (params: {
query: string; // PromQL or similar
timeRange: { start: Date; end: Date };
step?: string; // e.g., "1m", "5m"
}) => MetricSeries[];
"metrics.dashboard": (params: {
name: string;
}) => DashboardSnapshot;
// Traces (distributed tracing)
"traces.find": (params: {
service?: string;
traceId?: string;
minDuration?: number;
error?: boolean;
limit?: number;
}) => Trace[];
// Health
"health.check": (params: {
service: string;
environment: string;
}) => HealthStatus;
}
interface LogEntry {
timestamp: Date;
level: "debug" | "info" | "warn" | "error";
service: string;
message: string;
metadata: Record<string, unknown>;
}
interface HealthStatus {
status: "healthy" | "degraded" | "unhealthy";
checks: { name: string; status: string; message?: string }[];
lastCheck: Date;
}Alerts MCP Server
For incident response and on-call operations:
typescript
interface AlertsMCP {
"alerts.list": (params: {
status?: "firing" | "resolved" | "silenced";
severity?: "critical" | "warning" | "info";
service?: string;
}) => Alert[];
"alerts.ack": (params: {
alertId: string;
message: string;
}) => void;
"alerts.silence": (params: {
matchers: { label: string; value: string }[];
duration: string; // e.g., "2h", "1d"
reason: string;
}) => Silence;
"alerts.escalate": (params: {
alertId: string;
reason: string;
}) => void;
"runbook.fetch": (params: {
alertName: string;
}) => Runbook;
}
interface Alert {
id: string;
name: string;
severity: "critical" | "warning" | "info";
status: "firing" | "resolved" | "silenced";
service: string;
summary: string;
firedAt: Date;
resolvedAt?: Date;
labels: Record<string, string>;
}Legacy: Arm Domain Definition
typescript
interface ArmDomain {
name: string;
description: string;
defaultPatterns: string[]; // Glob patterns for auto-claiming
mcpServers: string[]; // Which MCP servers this arm can use
}
// Note: ArmDomain reflects an earlier design that relied on static domains.
// In the current design, arms are general-purpose and behavior is primarily
// guided by task classifications, task history, and configuration templates.Garden (Shared Environment)
The Garden is the workspace that arms tend. It's represented as a 3D space for visualization.
Layers
┌─────────────────────────────────────────────────────────────┐
│ THE GARDEN │
├─────────────────────────────────────────────────────────────┤
│ Physical Layer (files, dirs, repos): │
│ ├── Source code │
│ ├── Configuration │
│ ├── Documentation │
│ ├── Tests │
│ └── Build artifacts │
├─────────────────────────────────────────────────────────────┤
│ Logical Layer (exposed via MCP): │
│ ├── git-mcp - VCS operations │
│ ├── env-mcp - Environment variables │
│ ├── runtime-mcp - Node/Python/Bun versions │
│ ├── docs-mcp - Library documentation │
│ ├── nx-mcp - Monorepo orchestration │
│ ├── devtools-mcp - Browser automation │
│ ├── deploy-mcp - Deployment per environment │
│ └── pkg-mcp - Package management │
├─────────────────────────────────────────────────────────────┤
│ Ownership Layer: │
│ ├── Who owns what (claims) │
│ ├── Who touched what recently (activity) │
│ └── Conflict zones (multiple claims) │
└─────────────────────────────────────────────────────────────┘3D Coordinate System (Radial)
Files are positioned in a radial 3D space where distance from center indicates activity - frequently touched files appear closer to the center, making the visualization naturally focus attention on what's actively being worked on.
typescript
interface GardenCoordinate {
// Radial coordinates
category: number; // Angle in degrees (0-360) - which "slice" of the pie
activity: number; // Distance from center (0-100) - 0=hot, 100=cold
depth: number; // Vertical position (0-100) - stack layer
}
interface GardenNode {
path: string;
type: "file" | "directory";
coords: GardenCoordinate;
owner?: string; // Arm ID
lastTouchedBy?: string; // Arm ID
lastTouchedAt?: Date;
conflictZone: boolean;
}| Axis | Heuristic | Meaning |
|---|---|---|
| Category (angle) | File type/category | Each file category gets a slice: UI (0-60°), API (60-120°), DB (120-180°), Infra (180-240°), Tests (240-300°), Docs (300-360°) |
| Activity (radius) | Recency & frequency | 0=center=very active, 100=edge=dormant. Based on touches in last 7 days |
| Depth (vertical) | Stack layer | 0=frontend/surface, 100=infrastructure/deep |
Activity Calculation
typescript
function calculateActivity(path: string, touches: Touch[]): number {
const now = Date.now();
const weekMs = 7 * 24 * 60 * 60 * 1000;
// Only consider touches in last 7 days
const recentTouches = touches.filter(t =>
now - t.timestamp.getTime() < weekMs
);
if (recentTouches.length === 0) return 100; // Edge - dormant
// Score based on recency and frequency
let score = 0;
for (const touch of recentTouches) {
const ageMs = now - touch.timestamp.getTime();
const recencyWeight = 1 - (ageMs / weekMs); // 1.0 for now, 0.0 for week ago
score += recencyWeight;
}
// Normalize: more touches + more recent = closer to center
// Cap at 20 touches for max activity
const normalized = Math.min(score / 20, 1);
return Math.round((1 - normalized) * 100); // Invert: 0=active, 100=dormant
}Visual Effect
In the 3D Garden view:
- Center cluster: Files being actively worked on right now
- Middle ring: Recently touched, part of ongoing work
- Outer ring: Stable files, not recently modified
- Colored by owner: Each arm has a color, files glow with owner's color
- Pulsing: Files with active claims pulse gently
- Conflict zones: Red highlight when multiple arms are contending
Observatory (Web UI + API)
The Observatory is how humans observe and control the system.
Server Components
┌─────────────────────────────────────────────────────────────┐
│ OBSERVATORY │
├─────────────────────────────────────────────────────────────┤
│ Web Server (Hono): │
│ ├── REST API - CRUD operations, queries │
│ ├── WebSocket - Real-time updates │
│ ├── Static files - React SPA │
│ └── Push endpoint - Browser notifications │
└─────────────────────────────────────────────────────────────┘UI Views
| View | Purpose |
|---|---|
| Dashboard | System overview, arm status at a glance |
| Garden | 3D visualization of workspace with ownership |
| Arms | Arm details, context, activity log |
| Proposals | Active debates, arguments, signals |
| Approvals | Pending human decisions |
| Activity | Timeline of all system actions |
| Config | System settings, arm configuration |
Available Actions
- Spawn/Kill arms
- Approve/Reject proposals
- Override arm decisions
- Configure context budgets
- Reassign file ownership
- Trigger deployments
Model Fallback System
The model fallback system ensures arms can spawn successfully even when configured with unavailable models by automatically resolving to alternative models based on availability and cost.
Model Resolution Process
- Exact Match: Try the requested provider/model combination
- Provider Fallback: If model not found, find cheapest model from same provider
- Cross-Provider: If provider not available, find same model from another provider
- Last Resort: Use first available model from any connected provider
Model Pricing Information
The resolver includes known model pricing to make cost-based decisions when multiple fallback options are available:
typescript
interface ModelPricing {
input: number; // Price per million input tokens
output: number; // Price per million output tokens
}
// Examples of known model pricing:
// Claude Sonnet 4: { input: 3, output: 15 }
// GPT-4o: { input: 2.5, output: 10 }
// Gemini 2.5 Flash: { input: 0.075, output: 0.3 }Model Resolution Response
typescript
interface ResolvedModel {
providerId: string;
modelId: string;
providerName: string;
modelName: string;
fallback: boolean;
fallbackReason?: string;
}When a fallback occurs, the system logs the reason for debugging and transparency.
Provider Availability Checking
The system can validate model availability before spawning arms:
typescript
async function isModelAvailable(
providerId: string,
modelId: string,
apiUrl: string
): Promise<boolean>Cost-Based Model Selection
For scenarios where cost optimization is important, the system can provide a list of all available models sorted by cost:
typescript
async function getAvailableModelsByCost(
apiUrl: string
): Promise<Array<{ providerId: string; modelId: string; cost: number }>>Nerve System (Communication Layer)
All communication flows through the Nerve System using NATS for distributed messaging and an internal queue for brain↔arm messages.
Message Flow
Human ◄──────► Observatory ◄──────► Brain ◄──────► Arms
│ │ │
│ WebSocket │ NATS │ NATS/Queue
│ Push Notifications │ JetStream │ MCP Tools
│ REST API │ │NATS Event Types (Arm Lifecycle)
Events published via NATS for distributed arm management:
| Event Type | Direction | Description |
|---|---|---|
arm.spawned | Agent → All | Arm process started |
arm.killed | Agent → All | Arm process terminated |
arm.recovered | Agent → All | Arm recovered from error |
arm.status_changed | Agent → All | Arm status transition (idle→busy, etc.) |
arm.activity | Agent → Brain | Arm performed an action |
arm.log | Agent → Brain | Log message from arm |
agent.connected | Agent → All | Agent host came online |
agent.disconnected | Agent → All | Agent host went offline |
Queue Message Types (Brain ↔ Arm)
Messages passed through the brain's message queue:
| Message Type | Direction | Description |
|---|---|---|
task_assignment | Brain → Arm | Assign task to arm |
task_complete | Arm → Brain | Task finished successfully |
task_failed | Arm → Brain | Task failed with error |
discovery | Arm → Brain | Arm found something noteworthy |
dependency_discovery | Arm → Brain | Arm found a dependency |
status_report | Arm → Brain | Progress report on current task |
status_update | Arm → Brain | General status update |
heartbeat | Arm → Brain | Arm is alive and working |
approval_request | Arm → Brain | Arm needs approval for action |
approval_response | Brain → Arm | Approval granted/denied |
human_message | Human → Brain | Message from human |
share_note | Arm → All | Note shared between arms |
tool_discovery | Arm → Brain | Arm found useful tool |
doc_update | Brain → Arm | Documentation needs updating |
file_subscription | Arm → Brain | Arm watching a file |
file_change | Brain → Arm | Watched file changed |
claim_transfer | Brain → Arm | File claim transferred |
bug_report | Arm → Brain | Bug discovered |
bug_assignment | Brain → Arm | Bug assigned for fixing |
context_compression | Arm → Brain | Context was compressed |
dev_server_restart_request | Arm → Brain | Request to restart dev server |
Activity Event Types (JetStream)
Events tracked in JetStream for activity analysis:
| Category | Event Types |
|---|---|
| Session | session.status, session.idle, session.error, session.updated, session.diff |
| Message | message.updated, message.removed, message.part.updated, message.part.removed |
| Permission | permission.asked, permission.replied |
| Todo | todo.updated |
| File | file.edited, file.watcher.updated |
| Command | command.executed |
| Arm Lifecycle | arm.spawned, arm.status_changed, arm.heartbeat, arm.killed, arm.stopped |
| Task | task.created, task.assigned, task.claimed, task.completed, task.blocked, task.failed |
| Brain | arm_prompted, event-status, started, stopped |
